DANYANG FUXIN LIGHTING EQUIPMENT CO., LTD is a professional manufacturer of Outdoor Light Fixtures such as Street Light, Flood Light, Factory Light, Garden Light etc., located in Jiepai Down, Danyang city, Jiangsu, China. It has good techniques and strong strength. Integrating Die-casting, Sheet metal,
About us
-
![FGCL529]()
Item No. :FGCL529A FGCL529B Rated Power: 100-200W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞90lm/w MINI Luminous Flux ：9000lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Net Weight: 8.5kg 10kg Gross Weight: 9.5kg 11kg Packing Size:460x460x230mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FGCL529 ![FGCL531]()
Item No. :FGCL531A FGCL531B Rated Power: 120-180W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞100lm/w MINI Luminous Flux ：12000lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FGCL531
-
![FGCL534]()
Item No. :FGCL534 Rated Power: 100-200W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞110lm/w MINI Luminous Flux ：11000lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FGCL534 ![XL-LED-535]()
Item No. :FGCL534 Rated Power: 50-200W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞110lm/w MINI Luminous Flux ：5500lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Packing Size:300x140x120mm 540x140x120mm 780x140x120mm 1060x140x100mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver XL-LED-535
-
![FGTL321]()
FGTL321 Item No. :FGT321 Rated Power: 60-300W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞110lm/w MINI Luminous Flux ：6600lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Net Weight: 2.8kg 3.4 kg 4.2kg 5.3kg Gross Weight: 3.2kg 4kg 4.8kg 6kg Packing Size:320x390x275mm 400x390x275mm 480x380x275mm 560x390x275mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FGTL321 ![FGTL326]()
Item No. :FGT326 Rated Power: 90-240W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞110lm/w MINI Luminous Flux ：9900lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Net Weight: 3.5 kg 4.3kg Gross Weight: 4kg 4.8kg Packing Size:280x350x265mm 360x350x265mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FGTL326
-
![FGTL330A]()
FGTL330 Item No. :FGT330A FGTL330B FGTL330C Rated Power: 100-200W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞110lm/w MINI Luminous Flux ：11000lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK09 Life Span: 60000hours Net Weight: 3.8 kg 4.8kg 5.3kg Gross Weight: 4.3kg 5.3kg 5.9kg Packing Size:375x365x115mm 455x400x115mm 455x435x115mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FGTL330A ![FGTL330B]()
FGTL330 Item No. :FGT330A FGTL330B FGTL330C Rated Power: 100-200W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞110lm/w MINI Luminous Flux ：11000lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK09 Life Span: 60000hours Net Weight: 3.8 kg 4.8kg 5.3kg Gross Weight: 4.3kg 5.3kg 5.9kg Packing Size:375x365x115mm 455x400x115mm 455x435x115mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FGTL330B
-
-
-
![FZDL810]()
Item No. :FZDL810 Rated Power: 15-25W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞90lm/w MINI Luminous Flux ：1350lm Surge Protection: 4KV Working Temperature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Net Weight: kg Gross Weight: kg Packing Size:360x106x100mm Installation diameter: φ42 mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FZDL810 ![FZDH826-L]()
Item No. :FZDL826-L Rated Power: 20-60W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞90lm/w MINI Luminous Flux ：1800lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK09 Life Span: 60000hours Net Weight: 5.2kg 5.4kg 5.6kg Gross Weight: 5.7kg 5.9kg 6.1kg Packing Size:700x315x155mm Installation diameter: φ48 mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FZDH826-L
-
![FZDL817B－L]()
Item No. :FZDL817-L Rated Power: 60-120W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞90lm/w MINI Luminous Flux ：1800lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Net Weight: 4.8 kg 5.1kg 5.3kg Gross Weight: kg Packing Size: A 710x300x180mm B 936x333x190mm Installation diameter: Aφ42 mm Bφ60 Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FZDL817B－L ![FZDL847]()
Item No. :FZDL847 Rated Power: 25-60W Input Voltage: AC100-277V Frequency: 50/60Hz Power Factor: ＞0.92 Color Temperature: 3000-6500K Color rendering Index: ＞70 System Light Efficiency: ＞90lm/w MINI Luminous Flux ：2250lm Surge Protection: 4KV Working Temprature:-40℃to60℃ Insulation Class: classI IP Class: IP65 IK Class: IK08 Life Span: 60000hours Net Weight: 2.5 kg Gross Weight: 2.8 kg Packing Size:445x200x115mm Installation diameter: φ48 mm Remark: 1. Optional adjusted driver (0-10V or DALI) 2. could be equipped with 10KV lightning arrester; 3.Technical Data per to different brand of chips and driver FZDL847
